2005 Lagoon Royal Pilot Saloon 6520m

CONSTRUCTION

RCD Status & Classification:

• RCD Status: Our understanding is that the yacht is complies with the essential safety requirements of Directive 94/25EC (Recreational Craft Directive) and is marked as Category A (Unlimited Offshore)
• The yacht was designed and built to +YACHT I 3/3E/W +MACH class according to Rules for the Classification – Certification of Yachts Bureau Veritas

Hull Construction:

• WEST system wood/epoxy hull, deck and superstructure construction
• Hull frames, beams and floors made from laminated oak.
• Hull planking in triple overlapped layered Mahogany to 60mm thickness with 12 coats of epoxy externally and 8 coats internally.
• Underwater sections additionally laminated with 3 layers of glassfibre.
• Deck and bulkheads constructed in mahogany and marine plywood to 40mm thickness.
• Teak laid side decks, coachroof and cockpit
• Superstructure painted in white Awlgrip

Deck & Superstructure Construction:

• Deck and bulkheads constructed in marine plywood.
• Teak laid side decks, coachroof and cockpit
• Superstructure painted in white Awlgrip

Keel & Rudder:

• Encapsulated cast iron fin keel with lead ballast
• Balanced GRP spade rudder

MACHINERY

Engine & gearbox:

• Volvo Penta D5 A TA 4-cylinder turbo-charged diesel engine producing 140hp @ 1,900rpm
• Engine control via single lever control
• Freshwater cooling with heat exchanger and raw water intake and strainer.
• ZF Hurth 220 mechanical reverse gearbox
• Water-cooled exhaust system

Maintenance & Performance:

• Engine hours – approx. 1,750 as of Spring 2023
• Date of last engine service: September 2022
• Cruising speed – approx. 7.5 knots
• Maximum speed – approx. 10 knots

Propulsion & Steering:

• Shaft drive with stainless steel shaft driving supported by bronze p-bracket
• 3-bladed fixed pitch propeller
• Wheel steering with wood rimmed stainless steel helm wheel
• Hydraulic steering connection
• Emergency steering gear

ELECTRICAL SYSTEMS

Voltage systems:

• 24vDC domestic circuits with 12vDC start circuit and 220vAC via shorepower, generator or inverter
• DC & AC panel at navigation area with Mastervolt battery monitor system.

Battery Banks:

• 12vDC 140Ah AGM engine start battery
• 12vDC 140Ah AGM generator start battery
• 24vDC service battery bank

Charging/Inverter:

• Mastervolt 24vDC and 12vDC battery chargers
• Mastervolt inverter/charger with remote control

Alternators:

• 12vDC engine mounted alternator for the engine start batteries
• 24vDC engine mounted alternator for the services batteries

Generator:

• Mastervolt Whisper 12 Ultra 12kw 220vAC diesel generator
• Generator hours – approx 100 since fitment of new diesel engine – 2019
• Date of last generator service – April 2022

Other Electrical:

• 220v AC shore-power supply

PLUMBING & GAS SYSTEMS

Fresh Water:

• Pressurised hot & cold water system using 24vDC pressure pump assisted by pressure accumulator
• Water heated engine driven calorifier with 220v AC immersion element in well-insulated hot water tank.
• Hot & cold pressurised water supplies to galley and heads.

Watermaker:

• 220vAC reverse osmosis watermaker producing approx. 200 litres per hour

Bilge Pumps:

• 4x Jabsco electric bilge pumps
• Bilge alarm
• Manual bilge pump
• Gianneschi shower drain pumps

TANKAGE

Fuel:

• Approx 1,100 litres fuel capacity in 1x stainless steel tank
• Tank level gauge

Fresh Water:

• Approx 800 litres fresh water capacity in 2x Vetus plastic tanks
• Tank level gauge

Holding Tank:

• Approx 300 litres black water holding tank capacity in 1x Vetus plastic tank
• Tank level gauge
• Deck extraction and macerator pump for holding tank discharge

NAVIGATION & COMMUNICATION EQUIPMENT

In Cockpit:

• Raymarine RC631 colour radar chart plotter display with mast-mounted closed-array radar scanner
• Raymarine ST60 wind display
• Raymarine ST60 multi display
• Raytheon ST6000-series autopilot control
• Riviera steering compass

At Chart Table:

• Raymarine RL80C colour radar chart plotter display
• Raymarine ST60 speed display
• Raymarine ST60 depth display
• MRD80 Navtex receiver

Communications Equipment:

• Icom IC-M503 VHF with DSC at chart table

DOMESTIC EQUIPMENT

Galley:

• Stainless steel gimaballed stove with 4x 220vAC ceramic hobs and oven
• 220vAC microwave oven
• Dometic extractor above stove
• Coolmatic front opening 24vDC refrigerator
• Coolmatic front opening 24vDC freezer
• Stainless steel sink with hot & cold water supply.

Heads:

• Electric vacuum heads
• Hot & cold pressurised showers

Air-Conditioning:

• Climma Air 220vAC reverse cycle air-conditioning with 4 units

Laundry:

• 220vAC washing machine

Entertainment

• LCD TV in master cabin
• DVD connected to hi-fi
• 4 Clarion sound systems

ACCOMMODATION

Summary of Accommodation:

• 6 berths in 3 double cabins plus further twin crew cabin in forepeak
• Ensuite heads/showers to all accommodation cabins.
• Approx 2.12m headroom in saloon.

Accommodation Finish:

• Varnished mahogany joinery throughout using combination of veneered marine plywood panels and solid mahogany trims
• Teak sole board with holly inlay
• Cream leather upholstery in saloon
• Off-white headlinings with mahogany battening
• Synthetic stone counter tops in galley

Description of Accommodation from Forward:

• Crew cabin in forepeak accessed from deck with ensuite heads/shower.
• Master cabin forward with offset double berth to starboard, twin seats to port with vanity table and hanging lockers. Ensuite heads with vacuum heads and shower.
• Saloon amidships with u-shaped settee to starboard with dining table
• Further u-shaped saloon seating to port with small coffee table
• U-shaped galley aft to port on raised level
• Forward facing chart table area to starboard on raised level
• Mirrored port and starboard double aft guest cabins, with seats, hanging lockers and ensuite heads with vacuum heads and shower.

DECK EQUIPMENT

Rig:

• Keel-stepped white painted anodised mast
• Masthead rig with 3-sets of inline spreaders
• Stainless steel wire standing rigging – 2006
• Low-friction battencars for mainsail with track on mast
• Rod-vang
• Mechanical backstay adjustment
• Harken MkIII genoa and staysail furlers
• Single-line reefing system for mainsail
• Stainless steel Harken deck gear
• Checkstays
• Dyneema and Spectra running rigging

Winches:

• 2x Harken 2-speed self-tailing genoa winches adjacent to helm
• 2x Harken 2-speed self-tailing staysail winches adjacent to helm
• 2x Harken 2-speed self-tailing checkstay winches adjacent to helm
• 1x Harken 2-speed self-tailing mainsheet winch forward of helm
• 2x Harken 2-speed self-tailing halyard winches at mast base – one is electric

Sails:

• Hydranet Dacron fully-battened mainsail with 2-reefs
• Hydranet Dacron furling genoa
• Hydranet Dacron furling staysail
• Hydranet Dacron jib
• Nylon gennaker with sock

General:

• Stainless steel pushpit, pulpit and guardrail stanchions with side exits.
• Pushpit seats
• Varnished raised toerail
• Custom wood passarelle with guardrails

Anchoring & Mooring:

• Lewmar 3000 24v electric anchor windlass with deck buttoms
• 90lbs CQR anchor with chain
• Mooring warps and fenders

Covers, Cushions & Canvas:

• Stackpack mainsail cover with lazyjacks - 2022
• Bimini with stainless steel frame - 2022
• Canvas covers for raised saloon windows
• Winter full deck and cockpit canvas cover
• Winter topsides canvas covers
• Cockpit cushions
• Wheel cover
• Helm seat cover
• Winch covers
• Hatch covers

Tender:

• Arimar RIB tender
• Outboard engine

SAFETY EQUIPMENT:

General note on safety equipment: Any safety equipment such as liferafts, Epirbs, fire extinguishers and flares etc. are usually personal to the current owner(s) and if being left on-board as part of the sale of a used vessel may require routine servicing, replacement, or changing to meet a new owners specific needs.

• Life raft ISO 9002
• Flare pack
• Life lines
• Fire-extinguishers x 7
• Electric horn complete with loudspeaker
• Lifebuoy lights
• Life jackets
